Semi-automatic solder paste printer can be used for scraping solder paste, red glue and thermal grease on SMT production lines. The semi-automatic solder paste printer produced by Horrol Technology is incomparable with other brands on the market. Horrol brand solder paste printer uses slide rails all up and down, left and right to ensure the precision of the printer, and there will be no gap friction between the upper and lower rollers as in the past.
Technical parameter comparison table
—
| Device Model | HR-SAPP-400 | HR-SAPP-600 | HR-SAPP-1200 | HR-SAPP-1500 |
| Control Module | PLC Industrial Control | PLC Industrial Control | PLC Industrial Control | PLC Industrial Control |
| Dimensions | 700x900x1680mm | 900x900x1680mm | 1500x900x1680mm | 1800x900x1680mm |
| Workbench | 500x320mm | 700x320mm | 1300x320mm | 1600x320mm |
| Steel mesh allowable size | 600x450mm | 800x450mm | 1400x450mm | 1700x450mm |
| Power supply and load | 220v/0.3kw | 220v/0.3kw | 220v/0.3kw | 220v/0.3kw |
| Air pressure and flow | 4-6bar, ≤10L/min | 4-6bar, ≤10L/min | 4-6bar, ≤10L/min | 4-6bar, ≤10L/min |
| Active cylinder | SC63x150-S | SC63x150-S | SC63x150-S | SC63x150-S |
| Cutter head cylinder | CDU25x50 | CDU25x50 | CDU25x50 | CDU25x50 |
| Sliding rails | Linear Guides | Linear Guides | Linear Guides | Linear Guides |
| Printing accuracy | ±0.02mm | ±0.02mm | ±0.02mm | ±0.02mm |
| Fine-tuning range | ±10mm | ±10mm | ±10mm | ±10mm |
| Mobile Motor | Three-phase 60W | Three-phase 60W | Three-phase 60W | Three-phase 60W |
| Supply voltage | Single phase 220V | Single phase 220V | Single phase 220V | Single phase 220V |
| Movement Speed | 0~2200mm/min | 0~2200mm/min | 0~2200mm/min | 0~2200mm/min |
| Fault Detection | I/O signal detection | I/O signal detection | I/O signal detection | I/O signal detection |
| Direction of movement | Move left and right | Move left and right | Move left and right | Move left and right |
| Equipment weight | 195kg | 245kg | 280kg | 340kg |
The above parameters are for reference only. Please consult sales for customization.
Technical parameter comparison table
—
| Device Model | HR-SAPP-400 | HR-SAPP-600 | HR-SAPP-1200 | HR-SAPP-1500 |
| Control Module | PLC Industrial Control | PLC Industrial Control | PLC Industrial Control | PLC Industrial Control |
| Dimensions | 700x900x1680mm | 900x900x1680mm | 1500x900x1680mm | 1800x900x1680mm |
| Workbench | 500x320mm | 700x320mm | 1300x320mm | 1600x320mm |
| Steel mesh allowable size | 600x450mm | 800x450mm | 1400x450mm | 1700x450mm |
| Power supply and load | 220v/0.3kw | 220v/0.3kw | 220v/0.3kw | 220v/0.3kw |
| Air pressure and flow | 4-6bar, ≤10L/min | 4-6bar, ≤10L/min | 4-6bar, ≤10L/min | 4-6bar, ≤10L/min |
| Active cylinder | SC63x150-S | SC63x150-S | SC63x150-S | SC63x150-S |
| Cutter head cylinder | CDU25x50 | CDU25x50 | CDU25x50 | CDU25x50 |
| Sliding rails | Linear Guides | Linear Guides | Linear Guides | Linear Guides |
| Printing accuracy | ±0.02mm | ±0.02mm | ±0.02mm | ±0.02mm |
| Fine-tuning range | ±10mm | ±10mm | ±10mm | ±10mm |
| Mobile Motor | Three-phase 60W | Three-phase 60W | Three-phase 60W | Three-phase 60W |
| Supply voltage | Single phase 220V | Single phase 220V | Single phase 220V | Single phase 220V |
| Movement Speed | 0~2200mm/min | 0~2200mm/min | 0~2200mm/min | 0~2200mm/min |
| Fault Detection | I/O signal detection | I/O signal detection | I/O signal detection | I/O signal detection |
| Direction of movement | Move left and right | Move left and right | Move left and right | Move left and right |
| Equipment weight | 195kg | 245kg | 280kg | 340kg |
The above parameters are for reference only. Please consult sales for customization.
