Micro Loader Overview

The micro-board feeder is used for SMT board feeding. The whole equipment is composed of aluminum alloy frame, aluminum alloy grid, mold integrated aluminum alloy track and painted shell. The equipment has built-in anti-carding and automatic leveling functions. Both single and double panels can be adjusted. The grid slot plate of the micro-board feeder is fixed with left and right aluminum alloy plates. The dual motors control the grid slots separately, and the mechanical sensor rod automatically levels the circuit board. The electric chain pushes the board, which is stable and does not damage the circuit board without air connection.

There is no harm without comparison. Horrol Technology makes every penny you spend worth it. The micro-feeder uses ball screws to adjust the width and narrowness of the upper and lower tracks. The operation page automatically adjusts the width and narrowness of the track smoothly, saying goodbye to the T-type screw, and it is durable. The left and right sides of the transmission lifting track use double mechanical rods + sensors, which can realize the automatic leveling function with multiple protections.

The micro plate feeder uses an electric push plate, and the slide rail makes the movement of the slider smoother, smoother and more stable. The plate storage grid is made of black and white aluminum alloy, which is durable, wear-resistant and non-deformed, and can better identify the stored plates. The push rod direction can be freely switched to the left and right directions. The small plate loading machine uses a circulating plate storage grid, which can store plates in a cycle without manual waiting. There is no need to wait for manual work. The plate can be stored as long as there is space. The maximum number of plates stored each time can be 50. The small plate pusher uses thickened support rods and thickened and enlarged chains, which can be operated under heavy load. The push plate weight can reach 10kg and the load-bearing weight can reach 100kg.

The above parameters are for reference only. Please consult sales for customization.
